Stainless steel 316L liquid level transmitter with wide range of measuring

Stainless steel 316L liquid level transmitter with wide range of measuring

Quick Detail:

1.Advanced non contact measurement, not affected by medium density, viscosity, and the influence of high temperature changes

2. Using extremely stable materials. insturment has a good stability.

3. Can measure the liquid .solid medium level .

4. Can measure all the medium dielectric constant >1.6.

5.Measuring rang:0 - 60m

6. Resolution:1mm

7. Not affected by noise.steam.dust.empty space working condition and so on .

8. Process presure  reachable 4MPa. Process tempreture reachable 120 ℃

Description:

Guided wave radar transmitter works on the principle of time and travel. Radar wave travels at the velocity of light. The flying time is converted into level signal via the electronic components. The probe emits high frequency wave pulse which travels along a cable probe or a rod probe. When the wave pulse reaches the medium surface, it will be reflected and received by the receiver, and then the distance signal will be converted into level signals.

We have over 7 years experience in this line, Our daily output of radar level meter and ultrasonic level meter products reaches 10 sets. Our high quality product and good service have led us keep long good business relationship with many famous enterprises domestic and overseas.

Believe you will be satisfied with our product and service if you place a trial order with us. Looking forward to establishing cooperation relationship with your esteemed company.

Applications:

Coal plant, power plant,Petroleum and chemical industrial, Foodstuff Industrial, General Industrial Applcations.

Specifications:

Competitive Advantage:

1. Compitive price .

2. 18 months quality waranty.

3. long operation life and good after-sale service
